Rectangle LED Bathroom Mirror

Rectangle LED Bathroom Mirror
Product Introduction:
The Rectangle LED Bathroom Mirror spans two basin stations on a double vanity. A four-edge backlight frame covers the whole wash area, so two people share ample light. The 5 mm copper-free silver mirror has frosted edges, with white, warm or dual temperature options; length reaches 1.8 m or 2 m, and width adapts to cabinet depth across double-basin furniture.
Send Inquiry
Description
Technical Parameters
The Classic Partner for Double Vanities

The Rectangle LED Bathroom Mirror spans two basin stations on a double vanity. A four-edge backlight frame covers the whole wash area, so two people share ample light. The 5 mm copper-free silver mirror has frosted edges, with white, warm or dual temperature options; length reaches 1.8 m or 2 m, and width adapts to cabinet depth across double-basin furniture.

Solving Voltage Drop Across a Long Strip

On a 2 m panel the four-edge strip totals nearly six meters, and long strips lose voltage toward the far end, dimming the last section. Power enters from both ends: current flows toward the middle from each side, halving the path and evening brightness. The strip uses 2 oz copper foil, thicker than common 1 oz, for better conduction and reduced drop.

Hanger Layout for Large Weight

Large mirrors need planned hanger counts. A four-point layout places hangers near the rear corners; panels above 1.8 m add two middle hangers. Stainless hangers are 2 mm thick, each carrying 20 kg, far above the actual load. Positions are laser-marked on the back so installers place expansion screws without guesswork.

Straightness Control on Long Edges

Long glass wobbles more through the grinder than short pieces; the straight-edge machine adds support rollers at both feed ends, cradling the panel above and below. Ground long edges are checked against a ruler under inspection light, with deviation kept within 1 mm over 2 m; anything above returns for rework. The stricter bar keeps four edges visually straight after mounting. Rounded corners are available, with the strip following each arc.



Bulk Packing and Production Scheduling

Long mirrors ship in wooden crates filled with pearl cotton so contents cannot shift; panels under 2 m normally fit an elevator. aizhou Zhiyuan Electronic Technology Co., Ltd. schedules production by priority and supplies QC photos and videos during manufacturing. The Rectangle LED Bathroom Mirror is CE-LVD certified. Export packing uses cartons or honeycomb boxes lined with foam; electrical parts carry a two-year warranty.


Product Specifications

Parameter

Specification

Mirror material

5 mm copper-free silver mirror

Maximum size

Up to 2.2 m on one side

Lighting mode

Four-edge backlight frame

Strip power supply

Dual-end supply to prevent voltage drop

Mounting hangers

Four-point or six-point stainless steel support
