Oval LED Bathroom Mirror

Oval LED Bathroom Mirror
Product Introduction:
The Oval LED Bathroom Mirror pairs a soft oval contour with rear LED illumination. Built on a 5 mm copper-free silver mirror, its major and minor axes follow customer dimensions, while the strip traces the perimeter; lit, a ring of light outlines the shape beyond a plain oval panel. Curves carry no sharp corners, suiting households with children, and look more refined than square or round alternatives.
Send Inquiry
Description
Technical Parameters
Curved Lines Combined with LED Light

The Oval LED Bathroom Mirror pairs a soft oval contour with rear LED illumination. Built on a 5 mm copper-free silver mirror, its major and minor axes follow customer dimensions, while the strip traces the perimeter; lit, a ring of light outlines the shape beyond a plain oval panel. Curves carry no sharp corners, suiting households with children, and look more refined than square or round alternatives.

Oval Edging Is Far Harder Than Round Edging

A circle keeps constant curvature and finishes in one grinder pass; an oval changes curvature, tight at top and bottom and gentle at the ends. The special-shape grinder uses profile tracking: a sensor reads the outline in real time and adjusts wheel feed angle to hold consistent edge width. Stable parameters took nearly half a year of tuning to lock in.

Gentle Strip Bends at the Tightest Curves

The two peak-curvature zones demand the sharpest strip bends; forcing a normal strip through risks broken solder joints or loose beads. Installers instead begin a slow bend about 10 cm before each peak rather than turning sharply at the point. The extra labor keeps the strip under even stress and extends its life.

Ratio Guidance from Past Projects

No fixed oval ratio exists, but past orders suggest vertical ovals near 1.5:1 and horizontal near 1.6:1 look most balanced. A 2:1 elongated oval remains possible at higher difficulty; the workshop proposes a proportion from shared wall measurements before cutting. Vertical and horizontal hanging both work, set by stated orientation; the rear anti-shatter film sits behind the strip without obstructing it.



Custom Manufacturing and Sample Policy

The CNC glass center, special-shape grinder and film laminator support nonstandard shapes under OEM and ODM. MOQ is 10 pieces with mixed models; free CAD drawings precede production. Standard panels take 7-15 days, custom ovals 7-25 days; monthly output for simple styles exceeds 3,000 units. This Oval LED Bathroom Mirror is CE-LVD certified; electrical parts carry a two-year warranty.


Product Specifications

Parameter

Specification

Mirror material

5 mm copper-free silver mirror

Shape

Oval, major and minor axis ratio customizable

Recommended ratio

Vertical 1.5:1 / horizontal 1.6:1

Lighting mode

Backlight following the oval outline

Edge process

Profile-tracking special-shape grinding
