Polygonal LED Bathroom Mirror

Polygonal LED Bathroom Mirror
Product Introduction:
The Polygonal LED Bathroom Mirror is for customers who want unique design. The mirror can be hexagonal, octagonal, pentagonal, or any geometric shape. You can customize the side lengths and angles. The mirror is 5mm copper-free silver glass. The LED strip follows each side of the polygon.
Send Inquiry
Description
Technical Parameters
Hexagons and Octagons for Geometric Beauty

The Polygonal LED Bathroom Mirror is for customers who want unique design. The mirror can be hexagonal, octagonal, pentagonal, or any geometric shape. You can customize the side lengths and angles. The mirror is 5mm copper-free silver glass. The LED strip follows each side of the polygon. The backlight outlines the full polygon shape. When the light is on, every angle and every side is clearly defined. The geometric beauty stands out. Many designers use polygonal LED mirrors in concept hotels, high-end offices, or custom private homes.

CNC Is the Only Choice for Polygons

Polygonal mirrors need CNC processing. Precision is high. The error is small. Our standard for polygonal mirrors is this. The ground edge width must be even on every side. Each corner angle must stay at 90 degrees or your specified angle. The corners must not chip or break. This is harder than cutting a circle. But for our CNC equipment and experienced operators, it is routine.

Hexagon Is Our Most Popular Polygon

Among all polygons, hexagons are the most popular. Hexagons have natural symmetry. Like honeycomb shapes. The visual effect is balanced and modern. Each side length is usually 15 to 30cm. The overall diameter is 50 to 100cm. If the side length is too short (under 10cm), cutting and grinding become much harder. The edge chipping rate goes up. We recommend a minimum side length of 15cm. This gives good process quality and a visually pleasing hexagon.

Installation Orientation Matters

Polygonal mirrors are different from round or square mirrors. Some shapes, like hexagons, can be mounted in different orientations. Vertical point up. Point sideways. The visual effect changes a lot. Before installation, we suggest placing the mirror on the floor or a table. Look at it from different angles. Decide on the orientation you like best. Then mount it on the wall. We mark the top direction on the back. If you want a tilted orientation, tell us in advance. We will adjust the plate positions.




Specifications

Parameter

Specification

Mirror Material

5mm copper-free silver mirror

Shape

Polygon (hexagon, octagon, pentagon, etc.)

Processing Equipment

CNC processing center + segment grinding

Minimum Side Length

≥15cm (recommended for best quality)

Lighting Style

Backlight (along each side)



Frequently Asked Questions





Q: Can you make a polygon with any number of sides?

A: Yes. Pentagons, hexagons, octagons, decagons all work. More sides mean harder cutting.

Q: Are the polygon corners sharp?

A: Every corner is ground. The points are rounded (R-angle under 2mm). They are not sharp to the touch.

Q: Can a polygonal mirror have blast-proof film?

A: Yes. But film application on polygons is harder than on circles. It needs hand trimming. We will handle it.
